@hobo-sapiens

There isn’t a way in Windows 7 or Windows 10 to intercept a pending sleep state to run code before entering sleep mode. You can configure a scheduled task to run on the detection of a sleep event but the action to perform (Veyon update) happens not prior to entering a sleep state but actually occurs immediately after the computer wakes. So there could be a significant time delay between when the update is queued and when the update is actually performed.

I’ve not attempted to update Veyon with the master open but once the master computer exits sleep mode veyon-master.exe would likely still be in memory so it might be necessary to end the process. You could do this by the scheduled task I mentioned or as part of another update procedure.

The command would be:

"C:\Windows\System32\taskkill.exe" /f /im veyon-master.exe

Or remotely,

"C:\Windows\System32\taskkill.exe" /S computername /f /im veyon-master.exe

@antrax34

Students have Read access to Veyon$, but do the student computers have access to Veyon$?.

Using 4.5.1 I once noticed a delay in one computer appearing in the Master window. Connecting was unsuccessful but succeeded on a second attempt. The issue appeared transient and has not recurred.

Is the affected group name somehow special? What happens if you do not configure computer filters? Can you alternatively try to install Veyon 4.5.1 and replace libldap-common.dll in the installation directory with https://github.com/veyon/veyon/releases/download/v4.5.1/libldap-common.dll (make sure to stop the Veyon Service and any Veyon-related programs such as Master or Configurator before). It contains a minor improvement which might change the behaviour.

If it does not help, please change the log level to "Debug", stop Veyon Configurator, remove C:\Windows\Temp\VeyonConfigurator.log, start Configurator again and click the List all entries of a location button and enter the name of the affected group/location. Afterwards paste the content of C:\Windows\Temp\VeyonConfigurator.log so we can have a look at the related debug messages.

@tobydox

After updating to Veyon 4.5.1 the overlapping issue has not recurred. Everything is working perfectly.

Thank you.

No it's not a problem 🙂 To use Veyon with RDP sessions you have to enable multi session mode (https://docs.veyon.io/en/latest/admin/reference.html#refmultisessionmode) and access computers via the corresponding network ports, e.g. add computers with hostname "192.168.....:11101" to access the first RDP session, "192.168.....:11102" for the second RDP session and so on. Make sure to use Veyon 4.5.1 or a newer version. When working with RDP sessions it's recommended to use the NetworkDiscovery add-on which can also scan for sessions and provide them in Veyon Master dynamically.

I may have misinterpreted the question from the original post.

If I understand, the question is what are the steps to block all websites except for one.

To my knowledge there is no native facility within Windows to block websites by name aside from Hosts file entries. Windows Hosts files by current design do not allow for wildcard URI delimiters, so blocking all websites by name would prove a bit impractical. 🙂

Since most employees who oversee computer labs do not have management access to their employer’s DNS, DHCP and proxy resources one simple alternative to accomplish the task at hand is to implement an intermediate DNS server. The idea is to intercept and filter DNS lookups.

One such self-hosting DNS server/forwarder is the open source server Technitium.

https://technitium.com/dns/

https://download.technitium.com/dns/DnsServerPortable.zip

First download and unzip the portable version of Technitium to a shared server folder.

From the DnsServerPortable folder run DnsServerApp.exe using the Veyon master computer or for convenience, a domain/workgroup server computer to which you have access.

A command window will open showing the Technitium DNS server has started, the folder to which configuration settings are stored and the address to the web console.

Enter the displayed web address into a browser (http://computername:port/).

You will be prompted to set the Technitium admin account password.

The DNS server console will open as a page containing a series of tabs.

Open the Settings tab where you will see the server computer’s name (DNS Server Domain).

Scroll toward the bottom of the page and in the Forwarder section enter your organization’s DNS server IP addresses (usually there are two). The server addresses can be found by entering ipconfig /all at a Windows command prompt.

Example:
10.254.63.10
10.254.63.12

These entries are needed so that DNS lookups not handled by your Technitium DNS server will be forwarded to your regular DNS servers. Click the Save Settings button and then the Flush Cache button.

Next, open the Blocked Zones tab.

Click the Import button.

In the Blocked Zones window enter *.*to block all websites (note the asterisk delimiter) or any other particular URLs you wish blocked.

Examples:
youtube.com
www.youtube.com
*.youtube.com
*.app
*.ru

Click the blue Import button to close the Import Blocked Zones window.

You can use the blue Block button on the current tab to enter URLs individually.

The Export button downloads a text file containing currently blocked zones.

Use the Browse and Delete buttons to edit blocked entries.

Next, open the Allowed Zones tab.

In the same manner as with Blocked Zones enter and edit those URLs you wish to allow.
Referring to the original question, enter the one allowed URL.

In the final step you will need to change/set the DNS server address(es) at each student or client computer from your organization’s DNS servers to the Technitium DNS server.

At each computer open Network Connections by entering ncpa.cpl from a command prompt.

Right-click the listed Ethernet adapter and select Properties, (assuming IPv4) select Internet Protocol Version 4 (TCP/IPv4) then click the Properties button.

If static DNS entries are present replace those with the IP address of your Veyon master computer or the IP address of the domain/workgroup server from which you are running the Technitium DNS server.

Otherwise, select ‘Use the following DNS server addresses:’ then enter the Veyon master computer IP address (or domain/workgroup server IP address) as the Preferred DNS server entry. Leave the Alternate DNS server entry blank.

Click the OK button to accept the changes.

Access Control is set to LDAP Basic, Enable usage of domain groups and Grant Access to every authenticated user. No other access control rules set.

Any progress?

For some computers using Windows 10 the Power Options shutdown setting 'Turn on fast startup' may need to be disabled.

Disabling of advanced sleep modes within the BIOS may be necessary.

Updating network (ethernet) drivers could be required to allow disabling certain energy efficiency settings within the driver.

@MackenzieP

A tech at a neighboring school advised that rather than entering IP addresses into the Configurator’s Host address/IP field (Locations & computers) to instead enter computer names.

A bit confusing to me but he said to make the Host address/IP field match the Name field when using DHCP assigned addresses.

Yes, both.

As a workaround for monitoring audio you could install Stream What You Hear onto the client computers.

http://www.streamwhatyouhear.com/download/

Use the SWYH HTTP Live Streaming option and a player like Media Player Classic Home Cinema.

In SWYH settings choose a specific HTTP port and automatically run on log in.

From the MPC-HC File menu select Open File then enter the client computer streaming URL:
http://ip-address:port/stream/swyh.mp3 or http://computername:port/stream/swyh.mp3

Audio playing on the chosen client computer will be heard on the Veyon master computer.

From a command prompt:
"C:\Program Files\MPC-HC\mpc-hc64.exe" http://10.62.64.75:5901/stream/swyh.mp3
"C:\Program Files\MPC-HC\mpc-hc64.exe" http://LABx64075:5901/stream/swyh.mp3

A suggestion would be to create a folder of player shortcuts on the desktop, one for each client computer either by name or IP.

We've kept the default Configurator path even though the redirected H:\Pictures folder would be the more practical. The original Windows 10 default profile folders should still exist so setting the Screenshots path to C:\Users\username\Pictures would save the files locally.

You might try mapping a P: drive directly to the roaming profile share \\<servername>\<fileshare>\<username>.V6\Pictures then set Configurator to use P:\ drive for storing screenshots. No way for me to test here.

@tobydox
Request logins using accounts with blank passwords be allowed as a configurable option.

We use Active Directory to assign generic accounts to particular workstations by MAC address. In this way accounts without passwords are limited to logins at specific sets of computers where security is controlled at the machine level.

Our library uses the limited PATRON account for public catalog and database access and for general browsing of our collection. It would be convenient to log in our public computers en masse using this password-less account.

Students and faculty requiring broader access also have the option to log in using their assigned domain account.

@jrpfahl

Try turning off the Windows Defender Firewall (Domain Network) for one of the Windows 10 computers and try again.

Use the Veyon ‘Run program’ feature for running either a Devcon or PnPUtil script to disable (and enable) the device’s HID-compliant touch screen drivers using the specific HID\VID device instance path(s) and without the need to restart Windows.

devcon enable "@HID\VID_056A&PID_00E6&MI_01&COL05\8&27A6CAE3&0&0004"
devcon enable "@HID\VID_056A&PID_00E6&MI_01&COL01\8&27A6CAE3&0&0000"

devcon disable "@HID\VID_056A&PID_00E6&MI_01&COL05\8&27A6CAE3&0&0004"
devcon disable "@HID\VID_056A&PID_00E6&MI_01&COL01\8&27A6CAE3&0&0000"

Disabling touch in this manner should still allow pen input.
